VersaBoost™ Pro
VersaBoost™ Pro
The VersaBoost Pro series of all-in-one constant pressure boosting systems delivers consistent water pressure—even as demand changes. Built with the trusted quality of Franklin Electric, these compact units combine performance, reliability, and smart design. Easily installed and scaled with standard plumbing, VersaBoost Pro is ready for everything from everyday household use to demanding multi-pump applications.
Available on FE Connect
Discover the innovative FE Connect mobile app that enables you to remotely monitor and control your water system with ease and convenience.
Overview
Features & Benefits
- Powered by Franklin Electric encapsulated 4" submersible pump-motor assembly for superior performance and long life
- Franklin-engineered variable frequency drive delivers built-in protection, including underload, overload, overpressure, overheating, anti-cycling and freezing protection
- Versatile design with a 180° rotatable top cover and LCD display for multi-directional, front or rear plumbing applications
- Quick, easy-to-navigate setup assistant via its display menu or the FE Connect® mobile app
- Removable top, front and rear covers provide easy access to all components without disrupting the plumbing
- Rubber feet dampen noise from vibrations
- Integrated check valve and expansion tank included
- Rated for NEMA3R indoor or outdoor applications
- Quiet operation with a noise level as low as 45 dB
- Scalable for multi-pumping systems wirelessly up to 4 units in parallel
- Compatible with FE Connect for onsite connectivity and effortless troubleshooting enhanced with the One-to-One™ real-time remote feature
- Equipped with Bluetooth and WiFi to deliver customizable updates and notifications
- NSF/ANSI/CAN 61 & 372 certified & UL/CSA listed
Smart Control with FE Connect™
VersaBoost Pro connects 1-to-1 with Franklin Electric’s FE Connect app, giving you complete control at your fingertips. Whether installing, configuring, or servicing the system, Bluetooth connectivity makes setup fast and communication secure with no internet required.
Key Advantages
- Simple Bluetooth pairing for instant 1-to-1 connection
- Wireless setup and diagnostics via FE Connect app
- View live performance data and alerts in real time
- No Wi-Fi or extra hardware needed
Specifications
- Operational ranges available for up to 18 or 25 GPM
- Maximum suction lift: 25’ (7.6 m)
- Pressure options from 14 to 80 psi
- 120 and 240V models available
- 1” NPT inlet/outlet with molded-in hex grip with robust stainless-steel inserts
- Ambient operating temperature: 33°F to 122°F (0.5°C to 50°C)
- Maximum water temperature: 104°F (40°C)
- Maximum system pressure: 100 psi (6.9 bar)
Support Materials
Featured Downloads
Brochures
| Title | Type | Size | |
|---|---|---|---|
 |
Pressure Boosting System Comparison Tool | 0.84 MB | |
 |
Surface Pumps Brochure | 4.33 MB | |
 |
Water Systems Products and Applications Brochure | 5.61 MB | |
 |
Beyond the Pump Tools Services Brochure | 1.3 MB |
Catalogs
| Title | Type | Size | |
|---|---|---|---|
 |
Residential/Light Commercial Surface Pumps Catalog | 11.43 MB |
Parts & Accessories
| Item | Description |
|---|---|
| 305628101 | Replacement flow sensor and seal |
| 305628102 | Replacement pressure transducer (type recieved may vary) with seal and cable. |
| 305628103 | Replacement pressure tank. |
| 305628104 | Replacement check valve and top and bottom seals for the sensor pipe |
| 305628105 | Replacement priming port plug with seal and top cover hole blank insert. |
| 305628106 | Replacement hardware including all cover screws, plastic removable rivets for side covers, and adjustable feet with locknut. |
| 305628107 | Replacement side cover (1), can be used as front or rear (no labels included) |
| 305628108 | Replacement top cover assembly which includes a pre-installed installed user interface and digital screen |
| 305628109 | Replacement 115V power cord (6' long) |
| 305628110 | Replacement 230V power cord (6' long) |
| 10000022401 | Stainless Steel wall mount kit, includes hardware for physical assembly of the mount and additional hardware with vibration isolation for attaching the VersaBoost Pro or VersaBoost ProXT |
